英格索蘭90-250kW螺桿空壓機
由 合肥凱曠
英格索蘭90-250kW螺桿空壓機
品牌:美國英格索蘭
壓力:7 – 12 Barg
功率:90 – 250 kW
氣量:12.3 – 44.6 m3/min
機型 | 壓力 | 電機功率 | 排氣量 | 噪音 | 外形尺寸 | 重量 | ||
barg | kW | m3/min | dB(A) | 長 | 寬 | 高 | Kg | |
V90-7 | 7 | 90 | 17.1 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
V90-8 | 8 | 90 | 15.6 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
?V90-10 | 10 | 90 | 14.0 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
V90-12 | 12 | 90 | 12.3 | 72±3 | 3171 | 1574 | 1903 | 2703/2510 |
V110-7 | 7 | 110 | 20.5 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
?V110-8 | 8 | 110 | 19.6 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
V110-10 | 10 | 110 | 17.5 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
V110-12 | 12 | 110 | 15.4 | 72±3 | 3171 | 1574 | 1903 | 2833/2640 |
V132-7 | 7 | 132 | 24.1 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
V132-8 | 8 | 132 | 22.8 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
V132-10 | 10 | 132 | 21.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
V132-12 | 12 | 132 | 18.5 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
V160-7 V160-8 | 7 8 | 160 160 | 29.2 27.6 | 72±3 72±3 | 3171 3171 | 1574 1574 | 1903 1903 | 3160/2945 3160/2945 |
V160-10 | 10 | 160 | ?25.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
?V160-12 | 12 | 160 | ?22.0 | 72±3 | 3171 | 1574 | 1903 | 3160/2945 |
V250-7 | 7 | 250 | ?44.6 | 4000 | 1930 | 2175 | 4800/4900 | |
V250-8 | 8 | 250 | ??43.0 | 4000 | 1930 | 2175 | 4800/4900 | |
?V250-10 | 10 | 250 | ??38.8 | 4000 | 1930 | 2175 | 4800/4900 |
